HD/SDI H.265/H.264 Video Encoder

72,000.00 68,000.00

  • Model Number: MS-E1055S1
  • Brand Name: MSLiveBox
  • Package: Yes
  • Voltage: 110v
  • Input: 1*SDI,4*3.5mm Analog Audio
  • Output: TS over IP(1000M),1*SDI
  • Protocol: RTMP HLS HTTP UDP Unicast/Multicast
  • Resolution: Upto Full HD 1080P
  • Application: IPTV,OTT,Live Broadcast
  • Bitrate Mode: CBR,VBR
  • Color: Black
  • Video Encoding: H.264/MPEG4,H.265/Hevc
  • Audio Encoding: AAC,MP3
  • Configuration: Web Operation
  • HDCP: Support
  • OSD: Insert Logo&Text In Output Video Stream
Categories: ,


Share With love

The 1U Rack-mounted SDI Video Encoder with loop-out is our professional HD audio and video encoding device with powerful functionality. It is equipped with 1 channels SDI and 1 channels stereo audio(3.5mm) input supporting H.265& H.264 /AVC high profile /main profile /baseline profile coding format and two video streaming output each channel, which is streaming by HTTP, RTSP, UDP /RTP, RTMP, HLS, FLV, ONVIF. Also, there is 4 channel SDI loop out for local display. Its high integration and cost-effective design make this device widely used in a variety of field such as CATV digital head-end, hotel IPTV system, live streaming broadcast, streaming media server etc. Also, the encoder works with the online live broadcast platform, such as YouTube, Ustream, Twitter, Facebook, etc.
This encoder support SDI embedded audio or external audio optional from output video streaming each channel.

•   Support H.265 & H.264 /AVC baseline /main /high profile encoding
•   From 16 Kbit/s to 12 Mbit/s for CBR /VBR code rate controlling
•   Support HTTP, UDP /RTP, RTSP, RTMP, HLS, FLV, ONVIF streaming protocol
•   Support image, logo, text parameter settings on the output video streaming
•   Support English WEB operating interface and language customizable
•   Support output video streaming resolution setting(Up to 1920 * 1080P /30fps)
•   Support SDI embedded audio or external audio optional from output video streaming
•   Support GOP frame rate settings
•   Support output 2 RTMP (mainstream & 2nd stream) to different streaming media server each channel
•   Network interface full-duplex mode with 1000M speed
•   Support two video streamings output (Mainstream and second stream) each channel
•   Support HDCP and HD blue-ray
•   A wide area network remote management (Web control panel)
•   Support different protocol transmission for the mainstream & 2nd stream each channel
•   Support MP3 and AAC audio coding format selection
•   A click to restore the default configuration
•   Stable and effective, support 7 x 24h working time
